| Model | DS-2TD2636B-10/P | Brand | Hikvision | | Spec | 4MP | | |
High sensitivity thermal module with 384 x 288 resolution NETD is less than 40 mk (@25° C, F#=1.0) Leading thermal image processing technology: Adaptive AGC, DDE, 3D DNR Reliable fever detection alarm High quality optical module with 4 MP resolution Bi-spectrum image fusion, picture-in-picture preview
Thermal Image SensorVOx Uncooled Focal Plane Arrays Resolution384×288 Pixel Interval17μm Response Waveband8μm to 14μm NETDLess than 40 mK (@25°C,F#=1.0) Focal Length15mm Focus ModeAthermalized IFOV1.75 mrad ApertureF1.0 Field Of View37.5° × 28.5° (H × V) Min. Focusing Distance1 m
Optical Image Sensor1/2.7" Progressive Scan CMOS Resolution2688×1520, 4MP Min. IlluminationColor: 0.0089 Lux @(F1.6, AGC ON), B/W: 0.0018 Lux @(F1.6, AGC ON) Field Of View84° × 44.8° (H × V) Focal Length4mm Focus ModeFixed Shutter Speed1s to 1/100,000s White BalanceAuto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Daylight Lamp/Sodium Lamp Day & Night ModeIR cut filter with auto switch WDR120 dB
Smart Function Temperature MeasurementSupport 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line). Temperature RangeFrom 30°C to 45°C (86°F ~ 113°F) Temperature Accuracy± 0.5 °C
Network Main StreamThermal: 50fps(1280 × 720, 704 × 576, 384 × 288, 352 × 288);Optical: 50Hz: 25fps (1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720);Optical: 60Hz: 30fps (1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) Sub StreamThermal: 25fps(704 × 576, 352 × 288, 320 × 240);Optical: 50Hz: 25fps (704 × 576), 25fps (352 × 288), 25fps (176 × 144);Optical: 60Hz: 30fps (704 × 480), 30fps (352 × 240), 30fps (176 × 120) Video CompressionH.264 (Baseline/Main/High Profile) /MJPEG/H.265 Audio CompressionG .711u/G.711a/G.722.1/MP2L2/G.726/PCM ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK SecurityPassword protection, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP over HTTPS Simultaneous Live ViewUp to 20
Interface ClientiVMS-4200, Hik-Connect Web BrowserPlug-in required: IE8-IE11, Chrome 41-44, Firefox 30.0-51 Alarm Input2-ch inputs (0-5vDC) Alarm Output2-ch relay outputs, alarm response actions configurable Alarm ActionSD recording/Relay output/Smart capture/FTP upload/Email linkage Audio Input1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10% Audio OutputLinear Level; Impedance: 600Ω RS4851, RJ45 10M/100M Self-adaptive Ethernet interface. 1, RS-485 interface Analog Video Output1.0V [p-p]/75Ω, BNC, PAL/NTSC Communication Interface1, RJ45 10M/100M Self-adaptive Ethernet interface. 1, RS-485 interface On-Board StorageBuilt-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 128G), support manual/alarm recording
General Web Client Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) WiperNo User/Host LevelUp to 32 users, 3 levels: Administrator, Operator, User Power24 VAC ± 25%;12 VDC ± 25%;PoE (802.3af, class 3): 44 V to 57 V, 0.22 A to 0.17 A Power Consumption18 VAC to 30 VAC: 0.38 A to 0.22 A, max. 9 W 9 VDC to 15 VDC: 0.63 A to 1.06 A, max. 9 W PoE (802.3af, class 3): 44 V to 57 V, 0.22 A to 0.17 A, max. 9.5 W Work Temperature/HumidityFrom 10 °C to 35 °C (Indoor and windless environment use only); Humidity: 95% or Less Protection LevelIP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection Dimension376.1 mm × 119.1 mm × 118.1 mm (14.81" × 4.68" × 4.65") WeightApprox. 1.82 kg (4.01 lb)
|
